Amflow TL Carbon SUV E‑Bike

The Amflow TL Carbon is a full-suspension carbon e-bike supplied with a rear rack, mudguards, lights and a kickstand. Take the touring kit off and it is a 22.6kg trail bike. Leave it on and it is rated to a 200kg total system weight. NZ price $6,999.

125Nm
Avinox M2 peak torque
800Wh
Removable battery, up to 170km
120 / 105mm
FOX fork and rear shock travel
200kg
Maximum total system weight
The bike

What is the Amflow TL Carbon?

It is Amflow’s first touring and commuting e-bike: a full-suspension carbon bike fitted out for everyday use. Amflow calls it an SUV e-bike, meaning one bike set up for commuting, loaded touring and light trail riding.

The frame is full carbon and weighs 2.9kg. Suspension is a FOX AWL Sport fork with 120mm of travel and a FOX FLOAT Rhythm shock with 105mm, both tuned for the TL. Power comes from the Avinox M2 drive unit and an 800Wh battery that slides out of the down tube.

Amflow TL Carbon e-bike in Silica Beige, side view with the rear rack and front and rear mudguards fitted
NZ price $6,999
Frame Full carbon, 2.9kg, Silica Beige
Weight 22.6kg with the touring kit removed, 25.5kg as supplied (size S/M)
Drive unit Avinox M2, 110Nm nominal, 125Nm peak, 250W rated
Battery Avinox RS800, 800Wh, removable
Suspension FOX AWL Sport 120mm fork, FOX FLOAT Rhythm 105mm shock
Gears TRP E.A.S.I. 10-speed electronic derailleur with Avinox SmoothShift
Brakes Tektro TKD173 four-piston, 180mm rotors
Wheels 27.5in alloy, Maxxis Crossmark II 2.35in tyres
Sizes S/M and L/XL frames, covering riders about 155–191cm

The full specification and geometry are on the Amflow TL Carbon product page.

Two set-ups, one frame

How does the TL Carbon go from trail bike to tourer?

You add or remove the touring kit. The frame has mounts for the mudguards, rear rack, kickstand and an optional front rack, so the same bike can be set up for the trail one weekend and for a loaded trip the next.

Amflow TL Carbon in lightweight mode with the rack and mudguards removed, parked beside an alpine lake

Lightweight mode

Mudguards, racks and kickstand off
  • 22.6kg complete bike (size S/M), per Amflow
  • Meets ASTM F2043 Category 3 in this set-up, which covers rough trails that need some skill
  • Category 3 limits: 125kg maximum total weight and drops of up to 58cm
  • Front and rear both take 29in wheels and tyres up to 2.6in wide (racks and mudguards must come off with 29in at both ends)
Amflow TL Carbon with rear-rack panniers and a handlebar bag fitted, parked on a gravel path by the sea

Loaded mode

Touring kit fitted
  • Rear rack uses the MIK HD interface and is rated to 27kg
  • Optional front rack rated to 20kg (sold separately)
  • 200kg maximum total weight: bike, rider up to 125kg and both rack loads
  • Tows a bike trailer with Amflow’s trailer thru-axle kit (sold separately)
  • Rated ASTM F2043 Category 2 with the kit fitted: roads, gravel and smooth tracks
Two riders touring on Amflow TL Carbon e-bikes with bags fitted, climbing a grassy hillside under a clear sky
Motor and battery

What powers the Amflow TL Carbon?

The Avinox M2 drive unit. On the TL it is rated at 250W, with 110Nm of nominal torque and 125Nm peak. It has five assist modes and the motor itself weighs 2.6kg.

Close-up of the Avinox M2 drive unit and crank on an Amflow TL Carbon splashing through a puddle
  • Traction control. The drive unit reads its sensors and trims power to reduce rear-wheel slip on loose climbs.
  • SmoothShift. Paired with the TRP E.A.S.I. electronic derailleur, the motor turns the cassette so the gear changes without you pedalling. Amflow says the TL is the first bike to use it.
  • Controls. A 2in OLED Avinox display and a wireless controller on each side of the bar.
  • Charging. The supplied 168W charger takes the 800Wh battery from empty to 80% in 4h 38m and to full in 6h 03m. Avinox’s optional 508W fast charger does 0–80% in 1h 36m.
Cutaway render showing the Avinox 800Wh removable battery sliding out of the Amflow TL Carbon down tube

How far will the battery go?

Amflow quotes up to 170km (106 miles) from the 800Wh battery. That figure was measured on a flat sealed road with an 80kg rider in Eco mode at 21km/h, so hills, wind, cold, a loaded rack and higher assist modes will all bring it down.

For longer days, the optional Avinox 480Wh secondary battery takes total capacity to 1280Wh and adds up to about 100km (62 miles) under the same test.

Avinox Ride app

What smart features does the TL Carbon have?

Everything runs through the Avinox Ride app and the bar-mounted display. The main features:

Two riders on Amflow TL Carbon e-bikes on a gravel road at dusk, one with the front light switched on
Apple Find My
Check where the bike is and its battery level from your Apple device, or make it play a sound.
Route navigation
Load GPX, FIT or TCX routes in the app and follow turn guidance on the display. It shows the route line only, with no map.
Heart-rate assist
Pair a Bluetooth heart-rate monitor (sold separately) and the motor adds or reduces assist to hold you in your target zone.
Lights and updates
Switch the front light between high and low beam from the bar controllers. Firmware updates arrive over the air through the app.
Ready for the road

What comes with the Amflow TL Carbon?

The TL is supplied ready to ride on the road. Amflow’s standard specification includes the following, alongside the bike and battery.

01
Avinox front light
High and low beam, switched from the bar
02
Sate-lite M8 rear light
With an integrated reflector
03
Touring rear rack
MIK HD interface, rated to 27kg
04
Front and rear mudguards
Fitted as standard
05
Touring kickstand
348mm
06
Amflow Elite pedals
MTB pedals, supplied with the bike
07
Amflow bottle cage
Takes a compact bottle, about 450ml
08
Avinox 168W charger
Standard charger for the 800Wh battery
09
Two battery keys
For the removable battery lock
10
Torque wrench
For setting bolt torque correctly
11
Second stem
Swaps the frame between its two sizes
12
Dropper travel spacer
Reduces dropper travel by 10 or 20mm

Sold separately: the front rack, the 480Wh secondary battery, the 508W fast charger and the trailer thru-axle kit. We confirm the exact New Zealand specification with you when you reserve.

Fit

Which size Amflow TL Carbon do I need?

There are two frames, S/M and L/XL. Each is supplied with a short stem fitted and a longer stem in the box, and the stem is what sets the size on each frame. Amflow’s height guide:

Size Rider height Frame Stem Dropper
S 155–163cm S/M Short (fitted) 150mm
M 163–175cm S/M Long (supplied) 150mm
L 175–183cm L/XL Short (fitted) 170mm
XL 183–191cm L/XL Long (supplied) 170mm

If you are between sizes, add your height to the “Tell us about you and your riding” box in the reservation form and we will confirm the size with you before your bike is ordered.

First looks

What are reviewers saying about the TL Carbon?

The TL launched at Eurobike in June 2026, so the coverage so far is first looks rather than long-term tests.

Pinkbike
Pinkbike's first look ran under the headline “Amflow's €3,499 TL Carbon Could Be the E-Bike the Industry Didn't Know It Needed”, describing it as a carbon e-SUV that can do the shopping one day and an XC ride the next.
Read the article
BIKE Magazin
BIKE's first look said the TL's pricing could shake up the SUV e-bike market, and pointed to the modular rack and mudguards that turn it back into an off-road bike.
Read the article
Velomotion
Velomotion highlighted the 200kg maximum weight against a 22.6kg bike, and read the long 470mm chainstays as a sign it is built to stay stable and find traction when loaded.
Read the article
Reserve

How do I reserve an Amflow TL Carbon in NZ?

Fill in the form and tick TL Carbon. The first New Zealand bikes are on order. We will contact you to confirm size, timing and price before anything is ordered, and no payment is taken online.

Prefer to spread the cost? See our finance options.

Amflow Order Enquiry
Good to know

Amflow TL Carbon FAQ

How much does the Amflow TL Carbon cost in NZ?

$6,999 at Outset, in Silica Beige with Amflow’s standard 800Wh battery. The price is the same for the S/M and L/XL frames.

How heavy is the TL Carbon?

Amflow lists 22.6kg for an S/M bike with the mudguards, lights, pedals and rear rack removed, and 25.5kg as supplied. The L/XL is 22.9kg and 25.9kg. The frame alone is 2.9kg.

How far does it go on one charge?

Up to 170km from the 800Wh battery in Amflow’s test: flat sealed road, 80kg rider, Eco mode, 21km/h. Real rides with hills, wind or a loaded rack will be shorter. The optional 480Wh secondary battery adds up to about 100km.

How long does the battery take to charge?

With the supplied 168W charger, the 800Wh battery goes from empty to 80% in 4h 38m and to full in 6h 03m. Avinox’s optional 508W fast charger cuts that to 1h 36m and 2h 25m.

Can I ride the TL Carbon on mountain bike trails?

Yes, within limits. With the mudguards, racks and kickstand removed it meets ASTM F2043 Category 3, which covers rough trails that need some skill, up to a 125kg total weight and 58cm drops. With the touring kit fitted it is limited to Category 2: roads, gravel and smooth tracks.

Is the TL Carbon road legal in New Zealand?

Yes, on-road and off-road. The TL Carbon has no restrictions on where it can be ridden in NZ, so you can use it for road riding and mountain biking.

Can it carry panniers or tow a trailer?

Yes. The rear rack takes MIK HD bags and is rated to 27kg, and the optional front rack to 20kg. A trailer needs Amflow’s trailer thru-axle kit. Total weight, including you and the bike, must stay under 200kg.

Can I run the TL Carbon tubeless?

Not on the supplied wheels. Amflow says the stock wheelset does not support a tubeless conversion.

What warranty does it come with?

Amflow covers the carbon frame for 5 years for the original owner (2 years if the bike is sold on), the stem, bars, wheels and paint for 2 years, and supplied accessories for 1 year. The Avinox drive system is covered for 2 years, and the battery for 2 years or 500 charge cycles.

Who services the TL Carbon in Auckland?

Our workshop in Three Kings services Amflow bikes and the Avinox drive system, from diagnostics to full servicing. Book a service or call in.

Sources. Specifications, weights, range, charging, load ratings, sizing and warranty terms are from Amflow’s own pages:

NZ price and availability are from Outset.

Amflow TL Carbon

Want one of the first TL Carbons in New Zealand?

Reserve now and we will be in touch about size and timing. You can also browse the rest of the Amflow e-MTB range.
